Plans for Shapeoko 3 XXL Enclosure and Control box - Instant Download

$19.90

Instant Digital Download

(7)

PLANS INCLUDE:
- Detailed Assembly Drawings with Dimensions and Notes
- 4 cut sheet layouts (cuts made from stock 4'x8' & 2'x4' sheets of plywood)
- BOM (Enclosure Hardware and Electronic part list)
- Control box wiring schematic
- LED wiring schematic
- Supplementary pictures of assembly

BOM cost:
- Approximately $300 depending on what type of plywood and acrylic you choose to use

DIMENSIONS (to know if this would fit in your space):
- The overall width at the back is 48 inches, if you include the control box at the front left, then 53 inches wide.
- The overall depth is 43.5 inches.
- The overall height is about 58 inches (depends on the size of castor wheels you choose to put on the legs). Make sure to account for overhead space to open the front lid when it is open and resting on top.
